Atlas Scientific 3/8" Flow Meter

Specification

• Accurate to ± 2%
• Material Glass Reinforced PPO (Noryl)
• 3/8” Male NPT Input/Output
• Each pulse is equal to 367 μL
• Minimum flow rate 760 mL / min (0.2 GPM)
• Maximum flow rate 7.6 L / min (2 GPM)
• Weighs 37.6g
• Operating temperature -20º C to 80º C (-4º F to 176º F)
• Max operating pressure 1,379 KPA (200 PSI)
• Max viscosity 81 SSU
• 71.1cm (28”) long 3 lead cable
• Dimensions 16mm X 56.5mm (0.62" X 2.22")
• Food Safe
• Gasoline Safe
• Diesel Safe
• Kerosene Safe
• Includes 1 Flow Connector Board (soldering required)
